Red Probe 100mw/650 nm wavelength for superficial tissue penetration (power can be varied from 2mw to 100mw)
IR Probe 100mw/950nm wavelength for deeper tissue penetration( power can be varied from 2mw to 100mw)
Modulated frequency up to 10kHz. (frequency can be varied from 200Hz to 10kHz)
100mw probes can be switched to 25mw, 50mw, 75mw, 100mw by settings
Both the (Red & IR) probe tips covered by the plastic ceiling film to avoid infection when treating the open ‘wounds’
Energy can be varied from 0.01J to 100J (Biostimulation effect)
Energy density can be varied from 0.01J/cm² to 100J/cm²
100 preprogrammed pain condition wise (separately for IR & RED Laser) in alphabetic order.
100 user memory with patient name (Read & write)
Pulsed mode 10%,20%,30%,40%,50%……100%
Automatic calculation of power in mw, Energy in J and Energy density in J/cm²
All parameters will be displaying in wide graphic LCD size 240×128
(frequency, power, pulse ratio, Treatment time,
Treatment Area, Energy and Energy Density)
Sensor for IR Laser (Invisible Laser)
Laser principal, Formula and Contraindication will be displaying in the display.
Class 3B Laser
Laser type Semiconductor Ga As
